Gate leaves up to 1,8 m

Ideal solution for residential settingsMAIN FEATURES
Trilobe key release system.
Integrated, adjustable mechanical limit switches.
Simplified connections and one, three-conductor cable.
Supporting structure in die-cast aluminium.
Vite senza fine con copertura dedicata.
Ready for operation in case of power outage.
Fully covered and protected endless screw.
1
2
OPERATIONAL LIMITS
Ideal solution for residential settings

A18230
Max. length of leaf (m)
2,2
1,7
1
Max. weight of leaf (kg)
200
225
250
Max. leaf opening (°)
120
120
120

A1824
Max. length of leaf (m)
1,8
1,5
1
Max. weight of leaf (kg)
200
215
250
Max. leaf opening (°)
120
120
120
