Up to 800 kg
Solution for sliding gates at private homes
MAIN FEATURES
Encoder-based movement control.
Ready for installation of magnetic limit switches.
Control board with terminal blocks, display and storage for up to 250 users.
The safety inputs can be configured to directly control the 8k2Ω resistive sensitive-safety edges.
Self-diagnosing safety devices.
Developed with CONNECT technology for remote digital control via gateway or locally via CAME KEY.
Solution for sliding gates at private homes
S01MS-0021
Max. length of leaf (m)
14
Max. weight of leaf (kg)
400
Pinion module
4
S01MS-0031
Max. length of leaf (m)
14
Max. weight of leaf (kg)
800
Pinion module
4
