- Hikvision
- PRO Range
- NVR for IP cameras
- 16 CH PoE IEEE 802.3 af/at 200 W max.
- Supported incoming bandwidth 200 Mbps
- Maximum resolution 12 Mpx
- Compression H.265+/H.265/H.264+/H.264
- Outputs 4K HDMI & VGA
- Alarms
- Audio
- IP Dual Stream Access
- Mouse
- Space for 4 HDD
- WEB, CMS and Smartphone interface
- ONVIF Compatible
Features
- Hikvision
- PRO Range
- NVR recorder 16 CH IP PoE 200 W max.
- Maximum resolution 12Mpx@1ch : Alarms : Audio
- Bandwidth 200 Mbps
- Space for 4 hard disks
Specs
”
| Brand | Hikvision |
| Range | PRO |
| Inputs for IP cameras | LAN port up to 16 channels |
| Power over Ethernet | Switch of 16 PoE IEEE802.3af/at ports [%VAR%] (max. 200 W) |
| IP compatible cameras | HIKVISION (native protocol), ONVIF |
| Bidirectional audio | 1 RCA input / 1 RCA output |
| Video outputs | 1xHDMI 4K, 1xVGA independent |
| Video compression format | H.265+ / H.265 / H.264+ / H.264 |
| Display resolution | HDMI: 3840×2160, 2560×1440, 1920×1080, 1600×1200, 1280×1024, 1280×720, 1024×768 VGA: 1920×1080, 1280×1024, 1280×720, 1024×768 |
| Total bandwidth | 200 Mbps downstream / 160 Mbps upstream |
| Stream Type | Video / Video + Audio |
| Main Stream recording | 12MP /8MP /6MP /5MP /4MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF |
| Decoding capacity | 1CH@12Mpx, 2CH@8MPx, 4CH@4MP, 8CH@1080p |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Motion Detection | Yes |
| Alarms | 16 inputs / 4 relay |
| Recording method | Manual, programmed, motion detection |
| External Backup | USB memory / HDD USB / CD-RW USB / DVR-RW USB |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Remote connections | 64 |
| Internal memory | 4 HDD SATA 3.5″ of up to 10 TB each (not included) |
| Communication | 2 x USB 2.0 front, 1 x USB 3.0 rear / 1 x RJ45 10/100M (Ethernet) / 2 x RS-485 / 1 x RS-232 |
| Power | AC 100~240 V, ≤ 20 W (without HDD) |
| Operating temperature | -10ºC ~ 55ºC (10%-90% Humidity) |
| Dimensions / Weight | 75 (H) x 445 (W) x 400 (D) mm / 5 Kg (without HDD) |
Package content
- Hikvision NVR recorder
- Mouse
- Ethernet Cable
- Instructions Manual
- Hard disk connection wiring
- Power supply
“
