Doors with length up to 2 m

Ideal solution for fitting on swing-leaf and folding doors

MAIN FEATURES
24 V DC and 230 V AC EN versions tested thanks to the electronic management with encoder.
Quick and simple installation.
It can be installed either on the right or left thanks the symmetrical inputs on the gear shaft.
Protection rating against weathering agents (IP54).
In the 24 V DC versions it is possible to adjust the maneuvering speed, opening and closing slow-down speeds, and electronic detection of the obstacle.
Developed with CONNECT technology for remote digital control via gateway or locally via CAME KEY.

Ideal solution for fitting on swing-leaf and folding doors

F40230E
Max. width of leaf (m)
2
1,5
Max. weight of leaf (kg)
300
200

F4024E
Max. width of leaf (m)
1,5
1,2
Max. weight of leaf (kg)
200
150

F4024EP
Max. width of leaf (m)
2
1,5
Max. weight of leaf (kg)
300
200
